The MRC CALI-1200HN is a semi-portable, multi-hole and dry block type high temperature calibration furnace. It is an optimized solution to to calibrate high temperature sensors, (typically HT thermocouples) of different sizes at the same time.

Applications

• Steelworking,

• Glass Production,

• Metallurgical Processes,

• Cement Plants,

• Oil and Chemical Refineries,

• Fertilizers production,

• Thermal Power Stations.

Features

• Cost Effective High Temperature Furnace (Max. 1200°C).

• RS-232 Interface & Calibration Software as Option.

• Multi-hole Inserts (to suit).

• High Stability / Accuracy.

• Auto tune PID Temperature Control.

• Semi Portable – Castor Wheels.

• Forced air cooling provision.

Specifications

• Maximum Temperature : 1200˚C / 2192˚F,

• Minimum Temperature : 300˚C / 572˚F,

• Basic Accuracy: Better than ±3˚C,

• Stability : ±0.5˚C up to 600˚C & ±1˚C above 600˚C,

• Heating time to max. (incl. Insert) : 60 minutes,

• Cooling time (without Forced Air Cooling) : 2½ hours,

• Cooling time (with forced air cooling): 45 min. from 1200˚C to 300˚C,

• Multi hole insert : (4*7mm) + (3*9mm) or to suit,

• Max. Bore Diam.:  45mm ,

• Depth of Immersion: 150mm,

• Readout Resolution: 1˚C / 1˚F,

• Display Units: ˚C/˚F,

• Power consumption : 1850VA,

• 4mm Safety Socket,

• Switch Test Input: 5 VDC,

• Dimensions (w*d*h) : 205×365×475mm,

• Weight: Approx. 13Kgs.

• Environmental:

• Operating Temperature Range : 15-40˚C,
• Storage Temperature Range : -10-50˚C,
• Humidity range : 40-70% RH.

• Input Power:  110V/240V, 50/60Hz (240V recommended).

Optional / Accessories (Contact Labgear USA for Details.)

• Carrying case,

• Calibration software:  “Caltemp”,

• Calibration Certificate: NABL,

• RS232 COMMUNICATION: 9 pole, D-sub male,

• Forced Air cooling (Dry Compressed Air required).

---
